Embeddable Networking Cores
SWITCHCORE
Cores provide ethernet networking functionality in a stackable, modular form factor. This allows connectivity to be added to a baseboard to create product ready network switching, with minimal extra work.
With rugged stacking connectors and minimal footprints, BotBlox Cores mount directly onto your PCB layout for true connector flexibility, or onto our pre-designed baseboards. This provides ultra compact ethernet switching and sophisticated network management software as an embeddable module.
With NDAA section 889 qualified options, and MIL-STD-810H environmental performance, cores deliver the same reliability BotBlox products are known for, in an embeddable, modular design.
Ports
Dimensions
Functionality
Stacking header
Operating temperature (°C)
8 x 10/100 Mbps
27 x 27 x 11mm, 30 grams
VLAN, Port Management
Hirose DF40
-40 to +85
All
10Gbps
1Gbps
10/100Mbps
Cores are qualified to MIL-STD-810H and maintain operation from -40 to +85°C, making them suitable for integration into defence, aerospace, and industrial OEM platforms.
BotBlox Cores are embedded into custom platforms across multiple application domains.
Each integration brings different constraints on PCB real estate, thermal budget, and long-term supply chain requirements.
